Heavy Duty Gas Free Forging Offshore Drilling Spindle For Oil

The Heavy-Duty Offshore Drilling Spindle Free Forging is a precision-engineered forged component designed for high-load rotary systems in offshore oil and gas exploration. It functions as a key element in top drives, rotary tables, and drilling heads, transferring torque and axial load in critical downhole operations.

Forged from high-strength alloy steels such as 42CrMo4, this spindle offers exceptional fatigue resistance, torsional strength, and dimensional stability under extreme pressures, vibration, and corrosive environments. The free forging process ensures a directional grain structure optimized for high mechanical stress and long-term service life.

Key Features:

• Open-die forged for high-integrity performance in rotary drilling systems

• Customized dimensions: splines, threads, shoulders, and flange interfaces

• Heat treated (Q+T) for maximum strength and toughness

• 100% Ultrasonic Tested (UT) and Magnetic Particle Inspected (MPI)

• Optional Inconel cladding, anti-corrosion coating, or stress-relieving available

Applications:

• Offshore drilling rigs, land-based drilling systems

• Top drives, kelly drives, rotary tables, and mud motors

• Ideal for high-torque, high-shock, cyclic loading in deep well drilling


The steel forgings production flow:
Raw material steel ingot into warehouse(test the chemical composition) → Cutting→ Heating(Furnace temperature test) → Heat treatment after forging(Furnace temperature test) Discharge the furnace(blank inspection)→ Machining→ Inspection(UT,MT,Visal dimension, hardness)→ QT→ Inspection(UT, mechanical properties, hardness, grain size)→ Finish machining→ Inspection (dimension)→ Packing and Marking(steel stamp, mark)→ Storage Shipment.


Frequently Asked Questions (FAQs)
1. What is your forging weight range?
We produce forged parts ranging from 100 kg to 7000 kg.
2. Do you provide heat treatment and machining?
Yes, we offer full in-house heat treatment, rough, and finish machining services.
3. Which industries do you supply to?
We serve wind energy, heavy equipment, port machinery, transmission systems, and more.
4. What is your production lead time?
With stock: Around 30 days
Without stock: 40–45 days
5. Where is your factory located?
In Changzhou City, near Shanghai, with shipping via Shanghai Port.

Request a Quote
Please send your technical drawings and requirements to us. Our engineers will review and provide you with a professional quotation and solution shortly.
